Butterfly Valve Gear Operated 600mm

Approx Price:

₹83,955.00

Product: Cast Iron Butterfly Valve Wafer Type EPDM Lining Gear Operated
Size: 600mm (24″)
Disc Material: S.G Iron, SS304 / 316 (CF-8M)
Class: PN 10 / 16 / 25
Body Material: Cast Iron, Ductile Iron
Body Lining: EPDM / Nitrile
End Details: Suitable insertion between Flanges as per BS-10 Table D/E CI-125

Cast Iron Butterfly Valve with S.G Iron Disc – Gear Operated

Salient Features

Body Lining Integrally Moulded and Boded to body
One Piece Body Construction
Working Pressure: 16 Bar
Valve are Bi – Directional
Valve Shal Have Moulded Raised Face
Tight Shut Off Valve

Test Pressure (Hydrostatic)

Shell: 2.4 MPa
Seat: 1.76 MPa
Maximum Working Pressure: 1.6 MPa
Maximum Working Temperature: 90 C

Material List
Part No.	Name of Part	Material of Construction	Specification	Qty
1	Gear Box Assembly			1
2	Gasket	Steam Jointing Sheet		1
3	Body	Cast Iron	IS 210 FG 200	1
4	Disc	S.G Iron, SS304 / 316 (CF-8M)	IS 1865 Gr. 400/15	1
5	Upper Stem	Stainless Steel	IS 6603 Gr.12 Cr 12	1
6	Packing Bush	Bronze	IS 318 Gr. LTB 2	1
7	Lower Stem	Stainless Steel	IS 6603 Gr.12 Cr 12	1
8	‘O’ Ring	Nitrile Rubber	IS 5192-1	1
9	Bush	PTFE	BS EN 12086-1	1
10	L-Key Screw	Carbon Steel		1
11	C – Sunk Screw & Nuts	Carbon Steel		4 Each
12	Hand Wheel	Sheet Metal		1
13	Body Lining	EPDM/ Nitrile	IS 5192-1	1
14	Name Plate	Aluminium		1
1	Taper Pin	Stainless Steel	IS 6603 Gr.12 Cr 12	1

Size / Dimensions
Size (mm)	A	B	C	D
40	33	108	52	40
50	43	118	64	50
65	46	126	72	65
80	46	132	80	80
100	52	145	96	100
125	56	166	108	125
150	56	176	123	150
200	60	205	151	200
250	68	263	193	250
300	78	301	250	300
